VICTORY II

The PROMAG VICTORY II LED UV-A Handheld Lamp is designed for professional inspection applications that require dependable performance, portability, and durability. Built to comply with major international inspection standards, it delivers consistent UV-A illumination for accurate inspection results.

Download Materials

Datasheet

Product information:

Key Features

IP64 rating ensures dust-tight & water-resistant for field durability
Fully compliant with major global standards for reliable inspections
Lightweight 600g design for easy handling and improved portability
Long service life of over 20,000 hours
Supports both battery and AC power operation for flexibility and long-lasting performance
Fanless mechanical cooling system provides quiet and comfortable operation
Robust dual design for durability and stability, ensuring consistent inspection performance
Compact design allows for effortless portability across various inspection scenarios

Applications

Non-destructive testing (NDT) inspections
Fluorescent Penetrant Inspection (FPI)
Magnetic Particle Inspection (MPI)
Aerospace manufacturing and maintenance
Automotive inspection and quality assurance
Industrial quality control and defect detection
Maintenance, repair, and overhaul (MRO) operations

Technical Specifications

Power Supply: Mains powered & Battery
Light Source: LED UV-A & White Light LED
Dimension (L×W×H): 14×6.5×18 cm (5.51×2.56×7.09 in)
Weight: 600 g (1.3 lb) (with battery pack)
Visible Light in UV-A Mode (38cm): ≤2 foot-candles (20 lux)
Visible Light Intensity in Visible Mode (38cm): 20 foot-candles (200 lux)
Power Requirements: 90–240 VAC
Battery Pack
- Type: 12V, Li-ion rechargeable battery
- Run time: 3 hours continuous
- Full Charge Time: 6 hours

*The outcome may vary depending on the actual usage conditions.
*Once the product is disassembled, the waterproof warranty is void.

S/N	P7110-2	P7111-2	P7113-2
Type	VIC2-AS1 (UV-A Only)	VIC2-AS (UV-A + WH)	VIC2-SD (UV-A + WH)
UV-A Intensity at 15"(38 cm ) (μW/cm²)	< 5,000	< 5,000	≥ 8,000
UV-A Coverage Area at 15"(38 cm)Minimum 1,000 μW/cm²	Ø6.7 ± 0.4 in (17 ± 1 cm)	Ø6.7 ± 0.4 in (17 ± 1 cm)	Ø6.7 ± 0.4 in (17 ± 1 cm)
RRES 90061	✓	✓
AITM6-1001	✓	✓
ASTM E3022	✓	✓	✓
